Product Details:
|
| Height Range: | 1-2000mm / Customized | Diameter Range: | 1-40mm / Customzied |
|---|---|---|---|
| Flexural Strength: | 1250 MPa | Advantage: | Long Working Life |
| Item: | High-precision Yttria Stabilized Zirconia Ceramic Tubes For Watertight Valve | Density: | 6.0g/cm3 |
| Bibulous Rate: | <0.01% | Surface: | Smooth |
| Heat Expansion Rate (10-6K-1): | 10 | Color: | Black,yellow,white |
| High Light: | Smooth Zirconia Tube,Yttria Stabilized Zirconia Tube,High Precision Zirconia Tube |
||
High-precision Yttria Stabilized Zirconia Ceramic Tubes for Watertight valve
Description:
Zirconia tube is an extremely tough ceramic with a hardness of >9 Mohs which makes it and excellent material for extreme wear, high temperature and harsh environment applications.Zirconia tube have remarkable properties of strength, hardness and wear resistance in addition to withstanding attack from molten metal, organic solvents, acids and alkalis. They can also withstand high temperatures for long periods even under severe mechanical stress.
Our company has a number of technical personnel and a number of professional ceramic experts . We can solve the problems in the process of technology and ceramic forming for you. We have a complete set of ceramic production equipment and support to customize the drawings or to customize the samples .
Technical Parameters:
|
Performance |
Unit |
Typical value |
|
Density |
g/cm3 |
>6.0 |
|
HV Hardness |
Kg/mm2 |
>1300 |
|
Compressive Strength |
MPa |
5500 |
|
Flexural Strength |
MPa |
1250 |
|
Modulus of Elasticity |
Gpa |
200 |
|
Thermal Conductivity |
W/(m.k) |
3(20-400℃) |
|
Thermal Expansivity Cofficient |
10^-6K^-1 |
10 |
|
Facture Toughness |
Mpa.m0.5 |
8 |
|
Grain Size |
um | 0.5 |
Principal characteristic:
1. Outstanding wear resistance.
2. Great mechanical properties, with diamond-like hardness.
3. Exceptional corrosion resistance, it can withstand various strong acid and alkali, like HF, H2SO4.
4. Extraordinary electrical insulation, it always used in various high voltage, high-current application.
Application :
1. Dimensional accuracy:Up to 0.001mm.
2. Smoothness:Highest possible mirror(0.005mm).
3. Concentricity:Up to 0.003mm.
4. The inner hole tolerance: 0.005mm.
5. Straight flute:The narrowest 0.1x100mm.
6. The thickness of the size:Minimum to 0.02mm.
7. The screw thread:Minimum thread M2.
8. The smallest aperture:The minimum 0.07mm.
